APEX Gen3 5040
The Gen3 5040 is the newest and largest of our stages with the latest technology in mobile staging. This stage takes scalability and versatility to a new level. With a safer and easier setup and an overhead beam design that eliminates the “no fly zones” with ease, allowing endless options for hanging items from the … Continued
About the APEX Gen3 5040
The Gen3 5040 is the newest and largest of our stages with the latest technology in mobile staging. This stage takes scalability and versatility to a new level. With a safer and easier setup and an overhead beam design that eliminates the "no fly zones" with ease, allowing endless options for hanging items from the roof. The versatility of this stage will accommodate small to large events, making it the ideal stage for scalability. The Gen3 5040 features a combination use of aluminum and steel to maximize performance, and minimize trailer weight, a non-slip floor, and a five-section deck with the center section built on the trailer frame and a bi-folding deck on each side. The design allows for many configurations of speaker, video, and lighting hangst. The trailer frame is supported at six points by hydraulic controlled leveling outriggers which can vary the floor deck height in order to adapt to most terrains and venues within a 24" variation over the 50 foot deployed width.
Additional Details
- Dimensions: 50x40
- Load capacity: 102,000 lbs
- Towing Requirements: Standard Tandem 3 Axel Semi Tractor
- Time in Basic Mode: 2 hours with 8 stagehands
- Time in Beast Mode, with work wings and covers: 10 hours with 16 stagehands
